• 摘要: 增强型电荷耦合器件(ICCD)的性能直接影响源放大激光诱导击穿光谱(laser-induced breakdown spectroscopy, LIBS)的定量分析性能。研究不同ICCD制冷温度(10 ℃、0 ℃、−10 ℃、−20 ℃和−30 ℃)对源放大LIBS定性和定量分析水中氮的影响。研究发现,随着ICCD温度降低,定标曲线的线性相关决定系数R2由0.8098提升到0.9898;检测极限(limit of detection, LOD)由23.762 mg·L−1变化到0.131 mg·L−1;预测浓度的平均相对误差(average relative error,REAV)由34.97%减少至5.04%;交叉验证均方根误差(root mean square error of cross-validation, RMSECV)由19.8858 mg·L−1变化到4.8674 mg·L−1。实验结果表明,降低ICCD制冷温度能够提升LIBS的定量分析灵敏度和准确度。



      Abstract: The performance of the intensified charge-coupled device (ICCD) detector directly affects the quantitative analysis performance of plasma amplification laser-induced breakdown spectroscopy (LIBS). This study research on the impact of different ICCD cooling temperatures (10 ℃, 0 ℃, −10 ℃, −20 ℃, and −30 ℃) on plasma amplification LIBS analytical performance for analysis of N in water. The results shown that with the temperature decreased, the R2 of the calibration curve increased from 0.812 to 0.990, the limit of detection was reduced from 23.762 mg·L−1 to 0.131 mg·L−1; the average relative error (REAV) and root mean square error of cross-validation (RMSECV) were improved, which was reduced from 34.97% to 5.04% and 19.8858 mg·L−1 to 4.8674 mg·L−1, respectively. The experimental results demonstrate that reducing the ICCD cooling temperature can improve the sensitivity and accuracy of LIBS quantitative analysis.
