    • 摘要: 本文利用准连续纳米带组成的超表面设计了一种光学微分器件,并实现了对光学图像的一维边缘检测。该器件通过改变准连续纳米带的空间取向实现0~2π的几何相位调控,且能在较宽的波段范围内保持较高的能量效率。仿真结果表明,当照明波长从400 nm增加至1000 nm时,该准连续器件均能实现清晰的边缘检测效果。其能量效率最高为90.27% (600 nm波长处),平均能量效率为64.57% (400 nm~1000 nm)。可以预期,本文所提方法能促进准连续超表面在图像信息处理、超快光学模拟计算等方面的应用。



      Abstract: In this paper, we design an optical differential device based on quasi-continuous metasurface and realize one-dimensional edge detection of an optical image. By changing the spatial orientation of quasi-continuous nanostrips, the device achieves geometric phase in the range of 0~2π, and maintains high energy efficiency over a wide wavelength range. The simulation results show that when the illumination wavelength increases from 400 nm to 1000 nm, the quasi-continuous meta-device can achieve clear images for the target edge. The maximum energy efficiency is 90.27% (the incident wavelength is 600 nm) and the average energy efficiency is 64.57% (the incident wavelength changes from 400 nm to 1000 nm). It can be expected that the proposed method can promote the application of quasi-continuous metasurface in image information processing and ultrafast optical computation.
