Abstract:
In order to improve the contrast between the blood vessels and tissues of the images obtained by medical electronic endoscopes, a vessel enhancement method of non-linear contrast stretching in multi-color space is proposed according to the characteristics of endoscopic vascular images. Firstly, in RGB color space, stretching contrast adaptively of the green (G) component by using the nonlinear mapping function. Secondly, adjusting the gray value of the two components of red (R) and blue (B) according to the stretching result of the G component. Thirdly, converting the image to HSV color space, and stretching contrast adaptively of the saturation (S) component of the image. Finally, converting the image back to RGB color space, and the purpose of vessel enhancement is achieved. In this paper, the proposed algorithm is used to process several electronic endoscopic images with different contrast and brightness. The results show that the algorithm has better enhancement effect on small blood vessels which are not obvious in original features. Comparing to other enhancement methods, the detail variance (DV) of the enhanced image is significantly great. The algorithm is embedded in a resolution of 1280×800 endoscopic software, 26 frames can be processed per second.
